2 days ago Topic: separação de segmentos Tajima Software Administrator Posts: 538	Tajima Software Administrator Posts: 538 Topic: separação de segmentos Olá, Fabio. Pode separar partes de um segmento após dividi-lo usando a ferramenta Breakup do DG16. Para usar essa ferramenta, selecione qualquer segmento que tenha sido dividido em duas ou mais partes e pressione Ctrl+K ou clique com o botão direito do rato no segmento e escolha Shape > Breakup.

2 days ago Topic: Laser Cut Setting Tajima Software Administrator Posts: 538	Tajima Software Administrator Posts: 538 Topic: Laser Cut Setting Good morning Dave. Our development team is still working on the fix for the Laser Cut Velocity issue. It remains on our active list of priorities, though we don’t have a confirmed release timeline yet. We truly appreciate your continued patience, and we’ll notify you as soon as the update becomes available.

3 days ago Topic: Laser Cut Setting Dave Posts: 10	Dave Posts: 10 Topic: Laser Cut Setting Tajima Software wrote: Hi Dave, This issue is still being worked on. We understand it’s been in progress for some time and truly appreciate your continued patience. To help resolve this sooner, we’ll be sending you an early release of the next version of DG17 as soon as the fix is ready. Please don’t hesitate to reach out if you have any questions in the meantime. We’ll keep you updated as soon as there’s news. Good morning. Do you have any idea of a rough time frame for this update to be completed?

6 days ago Topic: separação de segmentos FábioR Posts: 1	FábioR Posts: 1 Topic: separação de segmentos Bom dia desde que mudei de computador e instalei o dg16 ilustrator extreme 16.5.3.7600 numa forma qualquer fechada ao selecionar nós e fazer divisao de vertices ele não deixa separar em segmentos porque será?

15 days ago Topic: Pick Color Tajima Software Administrator Posts: 538	Tajima Software Administrator Posts: 538 Topic: Pick Color Thank you for the request izšuvums.lv. We will move it forward.

17 days ago Topic: Pick Color izšuvums.lv Posts: 18	izšuvums.lv Posts: 18 Topic: Pick Color I want to thank you in advance for the Pick Color tool. I use this tool all the time! But there’s one small inconvenience. When you activate the Pick Color tool, it doesn’t recognize the palette you’ve set as default in User Settings. So each time, you have to pick your thread palette again from the long list of all available palettes. I’m not sure if this is a bug, but it would be great if the Pick Color tool automatically used the palette already set in the user settings.

17 days ago Topic: Pen Tooling Border Anchor/Handles MarkITMerch Posts: 4	MarkITMerch Posts: 4 Topic: Pen Tooling Border Anchor/Handles This ABSOLUTELY what we needed-- This will cut down on our tracing a TON. Thank You SO MUCH for your help!! Cheers. -BG

17 days ago Topic: Pen Tooling Border Anchor/Handles izšuvums.lv Posts: 18	izšuvums.lv Posts: 18 Topic: Pen Tooling Border Anchor/Handles Hi You still need to place additional nodes when digitizing, or adjust the handles of existing ones, which indeed takes quite a lot of time. Select the Pen tool (S) and switch it to Quickdraw mode by pressing the shortcut Q. A wavy line will appear next to your cursor. Now, when digitizing: the Left mouse button creates a sharp corner, and the Right mouse button creates a curved line. Place the first node where there’s a sharp corner by clicking the left mouse button, then move to the middle of a curved part of the shape and click the right mouse button to create a curved node. Continue to the next sharp corner and click the left mouse button again, and so on. The longer the curved section of the shape, the more curved nodes (RMB clicks) you’ll need to add. When you finish the contour and want to close the segment, press the shortcut O. In the screenshot I’m attaching, note the yellow line - I outlined this segment in 10 seconds using this method.

19 days ago Topic: Pen Tooling Border Anchor/Handles MarkITMerch Posts: 4	MarkITMerch Posts: 4 Topic: Pen Tooling Border Anchor/Handles Hi All, Wondering if there is a better way to redraw/pen around shapes and lettering when digitizing in DG15. I keep coming to a goofy point in my contours that leave the handles in WACKY positions trying to follow around shapes. I understand that adding the individual anchors (smaller increment) will keep the edges sharp, but it IS time consuming, as is the Stitch Column approach. I know you can just right-click around contours in Wilcom and the lines will hug the corners by cutting the difference between anchors. Any help would be MUCH appreciated. Thanks, Gang! -BG https://imgur.com/a/WAqRCdw

19 days ago Topic: Stitching Only Showing When Selected klbillen Posts: 30	klbillen Posts: 30 Topic: Stitching Only Showing When Selected OMGosh I have been fighting this exact thing for quite a while.... I also had that backwards! CHEERS!

20 days ago Topic: Stitching Only Showing When Selected MarkITMerch Posts: 4	MarkITMerch Posts: 4 Topic: Stitching Only Showing When Selected MY GOSH-- Thank You! I can't believe we had this backwards.. Appreciate the insight!

20 days ago Topic: Stitching Only Showing When Selected izšuvums.lv Posts: 18	izšuvums.lv Posts: 18 Topic: Stitching Only Showing When Selected MarkITMerch wrote: Hi All, Wondering if anyone could help us with a small view setting that we are experiencing: Stitches are only visible when paths are selected (Complex Fills and Satins). Once deselected, we can only see path outlines. View Active Group is on and View by Color (v) is stitching through the Sequence correctly. Any help is MUCH appreciated! Thanks, Gang. -BG Hi, You need to deactivate "View Active Group" The "View Active Group" setting is active! The "View Active Group" setting is inactive!

20 days ago Topic: Stitching Only Showing When Selected MarkITMerch Posts: 4	MarkITMerch Posts: 4 Topic: Stitching Only Showing When Selected Hi All, Wondering if anyone could help us with a small view setting that we are experiencing: Stitches are only visible when paths are selected (Complex Fills and Satins). Once deselected, we can only see path outlines. View Active Group is on and View by Color (v) is stitching through the Sequence correctly. Any help is MUCH appreciated! Thanks, Gang. -BG

21 days ago Topic: Draw Fusion and current version of CorelDraw TheFinishingTouch Posts: 20	TheFinishingTouch Posts: 20 Topic: Draw Fusion and current version of CorelDraw Luebbers, what version of CorelDRAW are you using? I don't see a "nodes tool" in my version of CorelDRAW (2019)

22 days ago Topic: Draw Fusion and current version of CorelDraw Luebbers Posts: 20	Luebbers Posts: 20 Topic: Draw Fusion and current version of CorelDraw I am going to guess that it will not. CorelDraw updates every year, and I do not see much effort in Pulse trying to stay current with that. However I never use Draw Fusion anyway. If I am bringing in vector art, I will open it up in CorelDraw first, then Ungroup all, then Select all and go to the nodes tool. Then I will select all again, and then click reduce nodes. Then I change the fill to none and the outline to black. Then size it up to you what you need and copy and paste it into Pulse. This method works all the time. The only problem is that you can't go in the opposite direction and copy in Pulse and past that into CorelDraw. I don't really see much need in doing that though.

22 days ago Topic: Draw Fusion and current version of CorelDraw messenJAH Posts: 3	messenJAH Posts: 3 Topic: Draw Fusion and current version of CorelDraw Is Draw Fusion ever going to be able to use current version of Corel Draw?

24 days ago Topic: Bug in the Edit Envelope tool Tajima Software Administrator Posts: 538	Tajima Software Administrator Posts: 538 Topic: Bug in the Edit Envelope tool Hello izšuvums.lv. Thank you for bringing this to our attention. We’ve confirmed that this behavior affects the Envelope tool when multiple segments are selected, and our development team is looking into it further. While we work on a fix, grouping the segments before applying an envelope should give you the expected results.

27 days ago Topic: Bug in the Edit Envelope tool izšuvums.lv Posts: 18	izšuvums.lv Posts: 18 Topic: Bug in the Edit Envelope tool Please tell me, have you been able to reproduce this bug on your side? And will it be fixed?

27 days ago Topic: View reports will not run Tajima Software Administrator Posts: 538	Tajima Software Administrator Posts: 538 Topic: View reports will not run Hello cfmwearables. This error is often related to the Windows user account permissions used by the Pulse Design Spooler service. Please try the following steps: Open the Control Panel. Open Administrative Tools (in Windows 11, search for Windows Tools) and select Services. Locate and open Pulse Design Spooler. Click Stop to stop the service. Select the Log On tab and choose "This account". Enter your Windows username and password. Click OK, then restart the service from the Services window. After restarting the spooler, please try generating the machine report again.

10/10/2025 Topic: Bug in the Edit Envelope tool izšuvums.lv Posts: 18	izšuvums.lv Posts: 18 Topic: Bug in the Edit Envelope tool It is impossible to use the Edit Envelope tool. All provided deformation shapes where non-corner deformation is offered do not work correctly. First, you can move the nodes marked with a red circle only once. After that, their selection is lost and you can no longer return to and move that node. With corner nodes marked with a green circle everything works perfectly. You can move it, confirm it, generate stitches, and continue moving the node further. Second, when selecting corner nodes, before stitch generation you can see via the outline how the design has been deformed. When selecting non-corner nodes this happens blindly and there is no way to see how the design has deformed at all. And given point one that you can effectively do this only once, it becomes pointless. Which makes it impossible to use this tool at all. The specified deformation shapes, that is anywhere deformation not only of the corners is offered, all have this bug. Also, Undo works incorrectly in Edit Envelope mode. It does not return the deformation to its original state. Instead it ruins the entire design and scatters elements into some kind of chaos. Meaning that if you decide to deform elements with Edit Envelope, you must do it with perfect precision, otherwise returning to the original state is impossible. Or you have to make a backup of the elements, which is rather silly. Please fix this in the upcoming updates. Otherwise this tool is essentially unfit for use.
